Max. working width 25-450mm
Max. working thickness 10-150mm
Min. working length 260mm
Max. cutting depth
(upper spindle) 4mm
Max. cutting depth
(bottom spindle) 4mm
Cutting Tool Spindle diameter 100mm
Spindle speed 4600r/min
Feeding speed 7-16m/min
Upper spindle motor power 7.5kw(10HP)
Bottom spindle motor 5.5kw(7.5HP)
Feeding motor power 2.2kw(Stepless speed)
Lifting motor power 0.37kw
Dust Exit Diameter 150mm
Total motor power 15.57kw
Net weight 2500kg
Overall Size 2500x1050x1750mm
Packing Size 2600x1150x1850mm
